Light Steel Keel Guage C U Channel Roll Forming Machine Ceiling Panel

Name: Light Steel Keel Guage C U Channel Roll Forming Machine Ceiling Panel
Brand: CHBEST
Price: 1 USD

China Light Steel Keel Guage C U Channel Roll Forming Machine Ceiling Panel wholesale

Brand Name : CHBEST

Model Number : XY50x50

Certification : CE/BV/SGS

Place of Origin : China Hebei

MOQ : 1 set

Supply Ability : 20 sets/month

Delivery Time : 30-40 days

Packaging Details : plastic film for naked machine

Product name : Light Steel Keel Guage C U Shape Roll Forming Machine Ceiling Panel

Color : Blue or according to your requirement

Control system : PLC

Cutting type : Non-stop cutting

Warranty : 2 years

Usage : ceiling drywall

Contact Now

Light Steel Keel Guage C U Channel Roll Forming Machine Ceiling Panel

Light keel forming machine has the features of high precision and high degree of automation. Our company can design and manufacture according to customers’ special requirements. Paint keel forming machine has the features of safe, high efficient synchronous punching and cutting, one-time completion of products, direct packaging, sizeprecision no worries for tolerance.

Working flow
Light Steel Keel Guage C U Channel Roll Forming Machine Ceiling Panel
Machine components

NO.	Name	Qty.
1	Decoiler	1set
2.	Roll forming machine	1set
3.	puncing and cutting machine	1set
4	control system	1pcs
5.	hydraulic station	1set
6	output table	1set

Parameter

1).Automatic inner tight decoiler

a.coil inner diameter 450mm-550mm

b. maximum width of coiling600mm

c. maximum weight of loading 2500kg

2). Main forming machine

a. number of forming steps 11rows

b. material of shaft 45# steel . Outer diameter 60mm

c.main motor power: 5.5kw

d. The speed of forming: 0-50m/min

3). Hydraulic cutter

a. material of blade:Cr12 mould steel with quenched treatment 60-62

b. cutting system :adopt advanced hydraulic drive, after forming automatic cut, no distort, no wasting , high safe factor.(tracking cutting)

4). The electrical control system

a. The Brand of display: DELTA

b.The main computer (PLC): DELTA DVP14

Light Steel Keel Guage C U Channel Roll Forming Machine Ceiling Panel

5). Hydraulic system

a. Adopting advanced hydraulic system of Tai Wan

b. Power:3kw

6). The equipments coating , package

a. the coating adopt international general shade-guide

b. The package :simple waterproof package.

Re-sale Service :	1. Send you invitation letter, if you want to visit our factory and check the machines. 2. Good Quality + Competitive price + Quick Response + Reliable Service.
Selling Service :	1. Email the production schedule and make prompt delivery. 2. Count the cheapest shipping cost, look for the fastest forwarder and send relevant documents promptly. 3. Be here for your service at any time
After-sale Service:	Any questions, contact us by WhatsApp or Telephone.

RFQ

Step 1: Tell us your requirements
Step 2: Quoataion will be sent based on your requirement. Solution will be recommended to you as the alternative
Step 3: Negotiate and confrim each details for goods, trading terms and so on, get agreement and sign contract.
Step 4: Advanced payment and production
Step 5: Factory Examine Goods/ rectify and reform to meet the requirements of contract.
Step 6: Balance payment and shipping
Step 7: Handing Shipping files to help clients get goods from transporter in time.
Step 8: Clients get goods and go into warranty time.
